ASME SA182 F304 SO RF Stainless Steel Flange Slip On Raised Face for Chemical and Industrial Piping

Ürün ayrıntıları:

Menşe yeri:	Çin
Marka adı:	YUHONG
Sertifika:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model numarası:	ASME SA182 F304

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1 adet
Fiyat:	NEGITABLE
Ambalaj bilgileri:	Kat-tahta sandık
Teslim süresi:	7 gün
Ödeme koşulları:	T/T, LC
Yetenek temini:	Ayda 100 Ton

İletişim

Tüm ürünler

Paslanmaz Çelik Dikişsiz Boru (308)

Paslanmaz Çelik Dikişsiz Boru (297)

Dubleks Paslanmaz Çelik Boru (132)

Dubleks Paslanmaz Çelik Boru (33)

İğne tüpü (134)

Fin Tüpü (672)

Isı eşanjörü (20)

Eşanjör Borusu (443)

Sıcaklık Değiştiricisi tüp kümesi (40)

Eşanjör Boru Sayfası (117)

ısı değiştiricisi baffle (37)

Klima (9)

Basınçlı kap (4)

Paslanmaz Çelik Kaynaklı Boru (58)

Paslanmaz Çelik Dikişli Boru (120)

Nikel Alaşım Boru (266)

Nikel Alaşımlı Boru (92)

Bakır Alaşımlı Boru (240)

Alaşımlı Çelik Boru (204)

titanyum tüp (15)

Parlak Tavlı Boru (155)

Kazan Borusu (151)

çelik uydurma (826)

Çelik Flanş (615)

Diğerleri (401)

Kaplama parçaları (7)

Detaylı ürün tanımı

Standart:	ASME SA182	Malzeme Sınıfı:	F304
Ürün Tipi:	Flanş Üzerinde Kayma	Malzeme:	Paslanmaz çelik
Yüz Tipi:	Yükseltilmiş Yüz (RF)	Başvuru:	Kimyasal ve Endüstriyel Borular
Vurgulamak:	ASME SA182 F304 stainless steel flange , slip on raised face flange , industrial piping stainless steel flange

ASME SA182 F304 SO RF Stainless Steel Flange Slip On Raised Face for Chemical and Industrial Piping

With over 35 years of manufacturing expertise and a global presence spanning 85 countries, YUHONG GROUP specializes in producing precision-engineered piping components for critical applications worldwide. Our ASME SA182 F304 Stainless Steel Slip-On Flanges with Raised Face are manufactured to the highest international standards, delivering reliable performance in chemical processing, industrial piping systems, and various demanding environments.

Heat Treatment Requirements for Grade F304 (UNS S30400)

Parameter	Specification	Notes
Grade (ASTM)	F304	Wrought Austenitic Stainless Steel
UNS Designation	S30400
Material Category	Austenitic Stainless Steels
Heat Treat Type	Solution Treat and Quench	Mandatory process
Solution Temperature, min	1900 °F [1040 °C]
Quenching Media	Liquid	Typically water
Tempering Temperature	Not Applicable	Austenitic stainless steels are generally not tempered

Chemical Composition of Grade F304 (UNS S30400)

Element	Requirement (%)
Carbon (C), max	0.08
Manganese (Mn), max	2
Phosphorus (P), max	0.045
Sulfur (S), max	0.03
Silicon (Si), max	0.75
Nickel (Ni)	8.00 - 10.50
Chromium (Cr)	18.00 - 20.00

Tensile and Hardness Requirements for Grade F304 (UNS S30400)

Property	Specification / Value	Notes
Grade Symbol (ASTM A182)	F304	Wrought Austenitic Stainless Steel
UNS Designation	S30400
Tensile Strength, min	75 ksi	515 MPa
Yield Strength (0.2% Offset), min	30 ksi	205 MPa
Elongation in 2 in. or 50 mm, min	30%
Reduction of Area, min	50%
Brinell Hardness Number (HBW)	...

ASME SA182 F304 SO RF Stainless Steel Flange - Key Application Advantages

1. Excellent Corrosion Resistance
Manufactured from ASTM A182 F304 stainless steel, providing outstanding resistance to corrosive media, making it ideal for chemical processing, marine, and acidic environments.
2 . Easy Installation and Maintenance
The slip-on (SO) design with raised face (RF) allows for quick alignment and simple installation, reducing assembly time and facilitating future maintenance.
3 . Reliable Sealing Performance
The raised face design ensures even gasket compression, creating a tight, leak-proof seal suitable for low to medium-pressure piping systems.
4. Wide Application Compatibility
Suitable for various industrial applications, including chemical plants, food processing, water treatment, and general industrial piping systems.
5. International Standard Compliance
Manufactured in full compliance with ASME SA182 standards, guaranteeing material quality and performance reliability for global projects.
