ASTM A335 P91 & P92 Seamless Steel Tubes High Temperature Chromium Molybdenum Alloy for Supercritical Power Plants

Ürün ayrıntıları:

Menşe yeri:	Çin
Marka adı:	YUHONG
Sertifika:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model numarası:	ASTM A335 P91 ve P92

Ödeme & teslimat koşulları:

Min sipariş miktarı:	500kgs
Fiyat:	Anlaşılabilir
Ambalaj bilgileri:	Plastik kapalı katlı kılıf / demir kasa / demet
Teslim süresi:	15-20 gün
Ödeme koşulları:	L/C, T/T
Yetenek temini:	800 Ton/ay

İletişim

Tüm ürünler

Paslanmaz Çelik Dikişsiz Boru (290)

Paslanmaz Çelik Dikişsiz Boru (277)

Dubleks Paslanmaz Çelik Boru (127)

Dubleks Paslanmaz Çelik Boru (29)

İğne tüpü (107)

Fin Tüpü (631)

Isı eşanjörü (17)

Eşanjör Borusu (424)

Sıcaklık Değiştiricisi tüp kümesi (37)

Eşanjör Boru Sayfası (116)

ısı değiştiricisi baffle (36)

Klima (8)

Basınçlı kap (4)

Paslanmaz Çelik Kaynaklı Boru (57)

Paslanmaz Çelik Dikişli Boru (114)

Nikel Alaşım Boru (261)

Nikel Alaşımlı Boru (79)

Bakır Alaşımlı Boru (227)

Alaşımlı Çelik Boru (184)

titanyum tüp (10)

Parlak Tavlı Boru (153)

Kazan Borusu (145)

çelik uydurma (804)

Çelik Flanş (590)

Diğerleri (391)

Kaplama parçaları (7)

Detaylı ürün tanımı

Standart:	ASTM A335/ASME SA335	Malzeme sınıfı:	P91 (UNS K91560) ve P92 (UNS K92460)
Ürün Tipi:	Dikişsiz çelik borular	Uygulama:	Enerji Santrali Kazanları, Yüksek Sıcaklık Boruları
Boyut aralığı:	Dış Çap 1/2" ila 24"	NDT Gereksinimleri:	UT, ET, HT Mevcut
Vurgulamak:	ASTM A335 P91 seamless steel tubes , high temperature chromium molybdenum alloy tubes , supercritical power plant alloy steel tubes

ASTM A335 P91 & P92 Seamless Steel Tubes High Temperature Chromium Molybdenum Alloy for Supercritical Power Plants

YUHONG GROUP is a specialized manufacturer with 35 years of experience in producing high-performance seamless steel tubes. Our ASTM A335 P91 & P92 chromium-molybdenum alloy tubes are engineered for supercritical power plants, offering exceptional high-temperature strength and oxidation resistance for global energy applications.

Chemical Composition Comparison: Grade P91 vs. P92

Element	P91 (UNS K90901) Requirement, %	P92 (UNS K92460) Requirement, %
Carbon (C)	0.08 - 0.12	0.07 - 0.13
Manganese (Mn)	0.30 - 0.60	0.30 - 0.60
Phosphorus (P), max	0.02	0.02
Sulfur (S), max	0.01	0.01
Silicon (Si)	0.20 - 0.50	0.50 max
Chromium (Cr)	8.00 - 9.50	8.50 - 9.50
Molybdenum (Mo)	0.85 - 1.05	0.30 - 0.60
Vanadium (V)	0.18 - 0.25	0.15 - 0.25
Niobium (Nb)	0.06 - 0.10	0.04 - 0.09
Nitrogen (N)	0.03 - 0.07	0.03 - 0.07
Nickel (Ni), max	0.4	0.4
Aluminum (Al), max	0.04	0.04
Tungsten (W)	-	1.50 - 2.00
Boron (B)	-	0.001 - 0.006

Heat Treatment Requirements: Grade P91 vs. P92

Parameter	P91 (Type 1 & 2)	P92	Key Notes
Grade	P91	P92	Both are high-strength creep-resistant alloy steels.
Heat Treat Type	Normalize and Temper or Quench and Temper	Normalize and Temper	A key difference: P91 allows for the alternative of Quenching.
Normalizing Temperature	1900-1975 °F [1040-1080 °C]	1900-1975 °F [1040-1080 °C]	The austenitizing temperature range is identical.
Cooling Media	Air or Accelerated Cooling	Air	P91 allows for accelerated cooling.
Tempering Temperature	1350-1470 °F [730-800 °C]	1350-1470 °F [730-800 °C]	The tempering temperature range is identical.
Tempering Temperature	1350-1470 °F [730-800 °C]	1350-1470 °F [730-800 °C]	P91: The maximum permissible tempering temperature is 1470 °F [800 °C].

Tensile Requirements Comparison: Grade P91 vs. P92

Property	P91 (Type 1 and Type 2)	P92	Notes
Grade	P91	P92, P93, P911, P36 Class 1	P92 shares its requirements with other advanced grades.
Tensile Strength, min	85 ksi	585 MPa	90 ksi
Yield Strength (0.2% Offset), min	60 ksi	415 MPa	64 ksi

Application Advantages of ASTM A335 P91 & P92 Seamless Steel Tubes

1. Excellent High-Temperature Performance
The P91 and P92 chromium-molybdenum alloy composition provides outstanding high-temperature strength and oxidation resistance, making them ideal for supercritical and ultra-supercritical power plants operating at temperatures up to 650°C.
2 . Superior Creep Resistance
These tubes offer excellent long-term creep resistance under high-temperature and high-pressure conditions, ensuring reliable performance in boiler systems, heat exchangers, and high-temperature piping applications.
3 . Enhanced Durability and Service Life
With superior resistance to thermal fatigue and oxidation, P91 and P92 tubes maintain structural integrity over extended periods, reducing maintenance requirements and increasing the lifespan of power generation equipment.
4. Global Standard Compliance
Manufactured in full compliance with ASTM A335/ASME SA335 international standards, these tubes are certified for use in critical applications worldwide, ensuring quality and safety across different markets.
5 . Wide Application Versatility
Suitable for various high-temperature environments, including power plant boilers, petrochemical processing units, and high-temperature pipeline systems, providing flexible solutions for diverse industrial needs.
