ASTM B163 N08810 Seamless Nickel and Nickel Alloy Condenser and Heat Exchanger Tubes

Ürün ayrıntıları:

Menşe yeri:	Çin
Marka adı:	YUHONG
Sertifika:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model numarası:	ASTM B163 N08810

Ödeme & teslimat koşulları:

Min sipariş miktarı:	500kgs
Fiyat:	Anlaşılabilir
Ambalaj bilgileri:	Plastik kapalı katlı kılıf / demir kasa / demet
Teslim süresi:	15-20 gün
Ödeme koşulları:	L/C, T/T
Yetenek temini:	800 Ton/ay

İletişim

Tüm ürünler

Paslanmaz Çelik Dikişsiz Boru (290)

Paslanmaz Çelik Dikişsiz Boru (277)

Dubleks Paslanmaz Çelik Boru (127)

Dubleks Paslanmaz Çelik Boru (29)

İğne tüpü (107)

Fin Tüpü (631)

Isı eşanjörü (17)

Eşanjör Borusu (424)

Sıcaklık Değiştiricisi tüp kümesi (37)

Eşanjör Boru Sayfası (116)

ısı değiştiricisi baffle (36)

Klima (8)

Basınçlı kap (4)

Paslanmaz Çelik Kaynaklı Boru (57)

Paslanmaz Çelik Dikişli Boru (114)

Nikel Alaşım Boru (261)

Nikel Alaşımlı Boru (79)

Bakır Alaşımlı Boru (227)

Alaşımlı Çelik Boru (184)

titanyum tüp (10)

Parlak Tavlı Boru (153)

Kazan Borusu (145)

çelik uydurma (804)

Çelik Flanş (590)

Diğerleri (391)

Kaplama parçaları (7)

Detaylı ürün tanımı

Standart:	ASTM B163/ASME SB163	Malzeme sınıfı:	N08810 (UNS N08810)
Ürün Tipi:	Dikişsiz tüp	Uygulama:	Eşanjör, Kondenser, Fırın Boruları
Boyut aralığı:	Dış Çap 1/8" ila 4"	Yüzey kalitesi:	Tavlanmış ve Turşu
Vurgulamak:	ASTM B163 N08810 nickel alloy tubes , seamless nickel condenser tubes , heat exchanger nickel alloy tubes

ASTM B163 N08810 Seamless Nickel and Nickel Alloy Condenser and Heat Exchanger Tubes

YUHONG GROUP is a specialized manufacturer with 35 years of industrial experience and a global presence spanning 85 countries, dedicated to producing high-performance nickel alloy tubing for critical applications. Our ASTM B163 N08810 seamless tubes are engineered for demanding heat exchanger and condenser systems, offering exceptional high-temperature strength and corrosion resistance for the chemical processing, power generation, and petrochemical industries worldwide.

Chemical Composition of UNS N08810 (Alloy 800H)

Element	Requirement (%)
Nickel (Ni)	30.0 - 35.0
Copper (Cu), max	0.75
Molybdenum (Mo)	-
Iron (Fe), min	39.5
Manganese (Mn), max	1.5
Carbon (C), max	0.1
Silicon (Si), max	1
Sulfur (S), max	0.015
Chromium (Cr)	19.0 - 23.0
Aluminum (Al)	0.15 - 0.60
Titanium (Ti)	0.15 - 0.60

Specifications for Nickel-Iron-Chromium Alloy UNS N08810 (Alloy 800H)

Parameter	Specification	Source / Notes
Alloy Common Name	Alloy 800H	High-carbon version for enhanced creep strength
UNS Designation	N08810
Condition (per TABLE 2)	Annealed
Primary Application Temperature	Above 1100°F (593°C)	Distinguished from N08800 (up to 1100°F)
Purpose of Annealing	To develop a controlled grain size	For optimum creep and rupture properties in high-temperature service

Mechanical Properties of Nickel-Iron-Chromium Alloy UNS N08810 (Alloy 800H)

Property	Specification
Alloy Common Name	Alloy 800H
UNS Designation	N08810
Condition	Annealed
Tensile Strength, min	65 ksi (448 MPa)
Yield Strength (0.2% Offset), min	25 ksi (172 MPa)
Elongation in 2 in. or 50 mm, min	30%

ASTM B163 N08810 Seamless Nickel Alloy Tubes - Key Application Advantages

1. Excellent High-Temperature Performance
The nickel-iron-chromium alloy composition (N08810) offers outstanding oxidation and carburization resistance, maintaining structural integrity at temperatures up to 1100°F (590°C), making it ideal for heat exchanger and furnace applications.
2. Superior Corrosion Resistance
Offers excellent resistance to various corrosive media, including oxidizing and reducing environments, making it suitable for chemical processing, power generation, and petrochemical industries.
3. Enhanced Mechanical Strength
The seamless manufacturing process ensures high tensile strength (≥520 MPa) and yield strength (≥205 MPa), providing reliable performance under high-pressure conditions in condenser and heat exchanger systems.
4. Long-Term Durability
Excellent resistance to thermal fatigue and creep deformation extends service life, reducing maintenance requirements and downtime in critical industrial equipment.
5. Wide Application Versatility
Suitable for various high-temperature components, including heat exchanger tubes, condenser tubes, and furnace parts, this solution offers flexible options for diverse industrial needs.
