ASTM B366 N08810 N08820 Equal Tee Incoloy 800H/800HT Tee, High Temp Corrosion Resistant For Piping System

Ürün ayrıntıları:

Menşe yeri:	Çin
Marka adı:	YUHONG
Sertifika:	API, PED , ABS, DNV, BV, LR
Model numarası:	ASTM B366 NO8810&N08820

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1 adet
Fiyat:	Anlaşılabilir
Ambalaj bilgileri:	KAT-AHŞAP KASA VEYA PALET
Teslim süresi:	miktarına bağlıdır
Ödeme koşulları:	T/T, L/C görüşte
Yetenek temini:	Ayda 10000 PCS

İletişim

Tüm ürünler

Paslanmaz Çelik Dikişsiz Boru (332)

Paslanmaz Çelik Dikişsiz Boru (324)

Dubleks Paslanmaz Çelik Boru (134)

Dubleks Paslanmaz Çelik Boru (37)

İğne tüpü (158)

Fin Tüpü (705)

Isı eşanjörü (31)

Eşanjör Borusu (459)

Sıcaklık Değiştiricisi tüp kümesi (49)

Eşanjör Boru Sayfası (125)

ısı değiştiricisi baffle (39)

Klima (11)

Basınçlı kap (4)

Paslanmaz Çelik Kaynaklı Boru (61)

Paslanmaz Çelik Dikişli Boru (132)

Nikel Alaşım Boru (273)

Nikel Alaşımlı Boru (103)

Bakır Alaşımlı Boru (250)

Alaşımlı Çelik Boru (210)

titanyum tüp (20)

Parlak Tavlı Boru (172)

Kazan Borusu (152)

çelik uydurma (862)

Çelik Flanş (660)

Diğerleri (406)

Kaplama parçaları (8)

Detaylı ürün tanımı

Standart:	ASTM B366 / ASME SB366	Ürün Adı:	eşit te
Od:	Müşterinin talebine göre	Ağırlık:	XXS Programlamak için 10'ları Planlayın
tip:	Sorunsuz	Sertifikalar:	ISO TÜV BV SGS, vb.
Boyut Standardı:	ASME/ANSI B16.9	Başvuru:	petrol gazı kimyasalı, Deniz ortamları, vb.
Vurgulamak:	ASTM B366 Incoloy 800H equal tee , high temperature corrosion resistant tee , N08810 N08820 piping system tee

ASTM B366 N08810 N08820 Equal Tee Incoloy 800H/800HT Tee, High Temp Corrosion Resistant For Piping System

ASTM B366 N08810 & N08820 equal diameter tees are special alloy pipe fittings designed to withstand extremely harsh high-temperature, high-pressure, and corrosive conditions, fundamentally solving the connection problems of core piping systems in the petrochemical, energy, and high-end manufacturing industries.

800H (N08810) - High-Temperature Reinforced Version: By specially increasing the carbon content (0.05%-0.10%) and combining it with high-temperature solution treatment, coarse austenitic grains are obtained, resulting in excellent creep resistance and end-of-life fracture strength at high temperatures. Due to its high chromium and high nickel content, it exhibits excellent resistance to stress corrosion cracking in corrosive media such as chlorides and high-temperature, high-pressure water.

800HT (N08820) - Enhanced High-Temperature Performance: Based on 800H, by more strictly controlling the content of carbon, aluminum, and titanium, its creep rupture strength at high temperatures is higher than that of 800H, while maintaining good strength and excellent resistance to oxidation and carburization.

Chemical Composition
Element	N08810 (Incoloy 800H)	N08820 (Incoloy 800HT)
Nickel (Ni)	30.0 – 35.0	30.0 – 35.0
Chromium (Cr)	19.0 – 23.0	19.0 – 23.0
Iron (Fe)	≥ 39.5 (Balance)	≥ 39.5 (Balance)
Carbon (C)	0.05 – 0.10	0.06 – 0.10
Manganese (Mn)	≤ 1.50	≤ 1.50
Silicon (Si)	≤ 1.00	≤ 1.00
Sulfur (S)	≤ 0.015	≤ 0.015
Copper (Cu)	≤ 0.75	≤ 0.75
Aluminum (Al)	0.15 – 0.60	0.25 – 0.60
Titanium (Ti)	0.15 – 0.60	0.25 – 0.60
Cobalt (Co)	—	≤ 2.00

Mechanical Properties
Property	N08810 (Incoloy 800H)	N08820 (Incoloy 800HT)
Tensile Strength (min.)	≥ 520 MPa (75 ksi)	≥ 520 – 870 MPa
Yield Strength – 0.2% offset (min.)	≥ 205 MPa (30 ksi)	≥ 205 – 345 MPa
Elongation (min.)	≥ 30%	≥ 30%
Hardness	≤ 200 HB (typical)	≤ 200 HB (typical)

Applications

Ethylene cracking furnace tubes;
Bellows and flare heads in oil refineries;
Intermediate heat exchangers in fourth-generation reactors;
Heat transfer tubes in high-temperature gas-cooled reactor steam generators;
Superheaters and reheaters in ultra-/ultra-supercritical boilers for thermal and solar thermal power generation.
